ISO LPG Tank Trailer/38.3m3 LPG Gas Tanker Semi Trailer with 3 Axle

  • >=1 Pieces
    $31,860.00
Model Number:
HT9300GYQ
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Use:
Truck Trailer
Type:
Semi-Trailer
Material:
Steel
Certification:
ASME
Size:
10470x2550x3920mm
OEM No.:
N
Max Payload:
18000KG
Place of Origin:
Hubei, China
Brand Name:
CIMC
Product name:
3-axle Semi-trailer
Gross Vehicle Weight:
29900KGS
Kerb Weight:
11900KGS
Design Pressure:
1.724MPa
Working Pressure:
1.724MPa
Design Temperature:
-20/50℃
Weight of Vessel:
7850KG
Tank Material:
SA-612M
Corrosion allowance:
0
Joint efficiency:
1.0mm
Supply Ability
Supply Ability:
500 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Nude packing
Port
Any Port in China
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Product Description

Main Technical Characteristic of 47.5 m³ LPG Propane Liquefied Gas Transport Semi-trailer

Total Mass
29900 KGS
Payload at 85%(S.G.=0.545)
18000 KGS
Kerb Mass
11900 KGS
Overal Dimensions
Length: 10470 mm Width: 2550 mm Height: 3920 mm
Design Pressure
1.72 MPa
Environmental Temperature
-20~50 ℃
Performance Datas
Volume
38.3 m³
Inside Diameter
2300 mm
Total Length of Vessel
10010 m
Maximu Allowable Working Pressure
1.72 MPa
Weight of Vessel
9200 KGS
Design Temperature
-20~50 ℃
S.G.
0.53 t/l
Hydrostatic Test Pressure
2.24 MPa
Welding Joint Coefficient
1.0
Corrosion Allowance
0
Material
SA-612M(N)
Thickness
12.5/8
Working Pressure
≤ 1.60 MPa
Certificates
Company Introduction

CIMC·Jingmen Hongtu Special Aircraft Manufacturing Co., Ltd. has 30 years experience in the design and manufacturing of storage and transportation equipments for liquefied gas and dangerous chemicals. The company has participated in the compiling of National TSG R0005-2011 Mobile Pressure Vessel Safety Technology Supervision Regulation and GB 18564.1-2006 Liquid & Dangerous Goods Transport Tank Vehicle Standards.


The company has developed 62 models of liquefied gas transport vehicle which features more than 30 patented technologies. For 20 years, the production and sales volume always ranks the first in domestic market, and the products have been exported to more than 40 countries and areas.


Hongtu liquefied gas transport vehicle is specially used for the road transport of liquefied gas like LPG, propane, propene, liquid ammonia, butadiene, iso-butane, and isobutene. The company has more than 30 core technologies including stress analysis and design, high strength light aluminum alloy weather board made of aeronautical materials with military manufacturing technology, wholly embedded safety valve, quadrangular outriggers, precision assembly between the tank and the travel mechanism, etc. as well as professional modular manufacturing lines, robot welding, etc. For more than 20 years, the company is always in the leading position and ranks the first in terms of market share in the domestic market

Workshop
Main Products

Semi-trailer


Bobtail/Rigid Tanker

ISO Tank /Tank Container

Spherical Tank

Horizontal/Mounded/Domestic Storage Tank

LPG Plant/Filling Plant/Autogas Station

LPG/Autogas Filling Skid

Contact US

Eric Chou
International Business Division
CIMC ENRIC•Jingmen Hongtu Special Aircraft Manufacturing CO.,LTD
No. 16, Yingchun Avenue, Jingmen City, Hubei Province, China
Mobile: +86-134 8093 1886 (Also whatsapp, wechat)
