52.6M3 LNG Liquefied Natural Gas Trailer 23.8 ton LNG Tank Truck

  • >=1 Sets
    $68,000.00
Model Number:
HT9400GDYF3
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 40 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Use:
Truck Trailer
Type:
Semi-Trailer
Material:
Stainless steel, steel
Size:
13000x2500x3900mm
Max Payload:
23800kg
Place of Origin:
China
Brand Name:
HONTO
Capacity:
52.6m3
Curb weight:
16200kg
Gross weight:
40000kg
Design temperature:
-196°C/50°C
Supply Ability
Supply Ability:
150 Set/Sets per Month
Packaging & Delivery
Packaging Details
Nude packge, with wax or with cover as per customer's requirement
Port
Shanghai, Wuhan or any port of China
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 40 To be negotiated
Product Description

LNG Semi Trailer

CIMC HONGTU has the ability to design and manufacture all kinds of refrigerated liquefied gas (LNG) tankers with high vacuum multi-layer insulation. The substance can be LNG, liquid oxygen, liquid nitrogen, liquid argon, liquid ethylene, liquid ethane, etc.

Technical Specification

Design codes: GB/T 150 Pressure Vessels, NB/T47058-2017 Road Tanker for Refrigerated Liquefied Gas, ASME BPVC SEC VIII-2
Capacity: 20m3~52.6m3
Material: S30408/SA-240 304(inner tank)/Q345R/SA-516(outer tank)

Specification
Design Code
Chinese GB standard
Total Weight
40000kg
Payload
23800kg
Net Weight
16200kg
Overall Dimension(L*W*H)
13000*2500*3900mm
Medium
LNG
Capacity
52.6m3

Inner tank
Outer tank
Design Pressure
0.65MPa
-0.1
Design Temperature
-196°C
50°C
Working Temperature
-162°C
Normal temperature
Corrosion Allowance
0
0
Main Material
X5CrNiN19-9/S30408/304
Q345R
Capacity
52.6m3/47.34m3
7.24m3 (interlayer)
Insulation Type
Hign-vacuum Multi-layer Heat Insulation
Packing & Delivery

Packaging: Nude or according to customer's requirements
Delivery: Ship in 40 days after payment
