40ft Fuel Tank Container Mobile Container Petrol Filling Station

  • >=1 Units
    $37,000.00
Model Number:
GX1107
Lead Time:
Quantity(Units) 1 - 1 >1
Est. Time(days) 90 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Capacity:
61m3
Place of Origin:
Hubei, China
Brand Name:
CIMC ENRIC Hongtu
Dimension(L*W*H):
12192*2438*2896mm
Weight:
14.43t
Certification:
GB
Warranty:
1 Year
After-sales Service Provided:
Field maintenance and repair service
kerb weight:
14430kg
charging mass:
43440kg
total mass:
57870kg
design capacity:
61m3
filling ratio:
0.95
Supply Ability
Supply Ability:
2000 Unit/Units per Month
Packaging & Delivery
Packaging Details
Nude packaging
Port
Jingzhou, Shanghai
Lead Time :
Quantity(Units) 1 - 1 >1
Est. Time(days) 90 To be negotiated
Product Description
Each petrol container is equipped with double-gun dispenser and the vapor recovery.
- 2 Fire extinguishers (8kg) shall be equipped for each container.
- Flow meter (Model No.: LC-80) shall be included in each container.
- Each tank container is equipped with one pump (Model No.:80CY2-A17).
- Two 3" BPS FORT brand male coupling (Model No.: 376X/1190A00, seal code:376V) for each container.
Technical Parameters of 40 Feet Mobile Petrol Filling Station
Container
40 Feet Mobile Petrol Filling Station
Curb weight
GX1107
Payload
43440kg
Total weight
14430kg
Capacity
61m3
Filling ratio
0.95
Filling media
petrol
Head Material
/
Leakage test pressure
36KPa
Outline dimension
12129*2438*2896mm
Tank
Design pressure
ordinary pressure
Design temperature
50℃
Inner tank material
Q235-B
Outer tank material
Q235-B
Corrosion allowance
1.0mm
Inner tank weight
6871kg
Tank dimension
10652*2210*2625mm
Packing & Delivery
Company Information

CIMC ENRIC • Jingmen Hongtu Special Aircraft Manufacturing Co., Ltd (hereinafter called Hongtu, and branded as HONTO) has made prominent contributions to the development of China's aviation industry since her establishment in 1971 as the AVIC Corp II factory No. 322. Now, Hongtu as a key enterprise under China International Marine Containers (Group) Ltd. (CIMC) (ranked 68th in Chinese Top 500 businesses), is engaged in R&D of normal temperature storage & transportation equipment and cryogenic storage & transportation equipment, EPC contracting, chemical equipment and other types of energy chemical storage & transportation equipment. The Company has employed more than 1,300 people, including approx. 400 R&D professionals, and has workshop area totaling 130,000 m2.

The Company always stands in the forefront leading the industrial development. "HONTO" Brand LPG tanker's production and sales has ranked No.1 in China for the past three decades with a domestic market share over 60% all along. Hongtu has been engaged in the manufacturing of energy and chemical storage & transportation equipment for over 3 decades and is also the only LPG full-industrial chain equipment manufacturer and solution provider in China.

"HONTO" brand LPG storage and transportation equipment has been distributed to more than 32 countries in America, Middle East, South America, Southeast Asia, Northeast Asia and Africa.

Main Products

 Semi-trailer

 Bobtail/Rigid Tanker

 ISO Tank /Tank Container

 Spherical Tank

 Horizontal/Mounded/Domestic Storage Tank

LPG Plant/Filling Plant/Autogas Station

LPG/Autogas Filling Skid

Certificates

ASME U Certificate

ASME U2 Certificate

Member of World LPG Association

National Board of Boiler & Pressure Vessel Inspection

Contact Us

Caroline Deng
International Business Division
CIMC ENRIC•Jingmen Hongtu Special Aircraft Manufacturing CO.,LTD
No. 16, Yingchun Avenue, Jingmen City, Hubei Province, China
Mobile: +86-18608698970 (Also whatsapp, wechat)
Email: dengmengjie(@)enricgroup.com
