51.1m3 27.083 tons Three Axles Semi-trailer Anhydrous liquid ammonia semi trailer

FOB Reference Price:Get Latest Price
$30,000.00 - $40,000.00 / Pieces | 1 Piece/Pieces (Min. Order)
Model Number:
LPG-FA-180710-1 - 01
Lead Time:
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 180 Negotiable
Report Suspicious Activity
Overview
Quick Details
Use:
Truck Trailer
Type:
Semi-Trailer
Material:
Steel
Certification:
China GB Standard
Size:
13290x2550x3900 mm
OEM No.:
1
Max Payload:
27083kg
Place of Origin:
Hubei, China
Brand Name:
CIMC Enric Hongtu
Kerb Weight:
12917kg
Gross Vehicle Weight:
40000kg
Design pressure:
1.91 MPa
Design Temperature:
-20/+50℃
Filling weight per volume:
0.53 t/m3
Welding Joint Coefficient:
1.0
Tank/Head Material:
Q420R(Normalizing)/Q345R(Normalizing)
Corrosion Allowance:
2.0 mm
Air Test Pressure:
1.91 MPa
Hydraulic Test Pressure:
2.49 MPa
Supply Ability
Supply Ability:
50 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
international standard
Port
any port in China
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 180 To be negotiated
Product Description

Main Technical Characteristic of 51.1m³ Three Axles Anhydrous Ammonia Semi-trailer

Semi Trailer
Kerb weight
12917kg
Payload
27083kg
GVW
40000kg
Full Load
Keyway
16000kg
Rear Axle Load
24000kg
Design the Limited Velocity
Straight Road
According to "Rules of Transportation, Loading and Unloading of Dangerous Goods by Automobile" (JT618)
Turning
15 km/h
Design Pressure
1.91 MPa
Water Capacity
51.1 m³
Design Temperature
-20/50℃
External Dimension (LengthxWeightxHeight)
13290x2550x3900 mm
Tank
Filling Medium
Ammonia
Filling weight per volume
0.53 t/m3
Welding Joint Coefficiency
1.0
Tank/Head Material
Q420R(Normalizing)/Q345R(Normalizing)
Corossion Allowance
2.0 mm
Service Years
10 years
Air Test Pressure
1.91 MPa
Hydraulic Test Pressure
2.49 MPa
Tank Mass
10000kg
External Dimension (Inside DiameterxThicknessxLength)
2310x8.5/11.5x12992 mm
Certifications
Company Introduction

CIMC·Jingmen Hongtu Special Aircraft Manufacturing Co., Ltd. has 30 years experience in the design and manufacturing of storage and transportation equipments for liquefied gas and dangerous chemicals. The company has participated in the compiling of National TSG R0005-2011 Mobile Pressure Vessel Safety Technology Supervision Regulation and GB 18564.1-2006 Liquid & Dangerous Goods Transport Tank Vehicle Standards.

The company has developed 62 models of liquefied gas transport vehicle which features more than 30 patented technologies. For 20 years, the production and sales volume always ranks the first in domestic market, and the products have been exported to more than 40 countries and areas.

Hongtu liquefied gas transport vehicle is specially used for the road transport of liquefied gas like LPG, propane, propene, liquid ammonia, butadiene, iso-butane, and isobutene. The company has more than 30 core technologies including stress analysis and design, high strength light aluminum alloy weather board made of aeronautical materials with military manufacturing technology, wholly embedded safety valve, quadrangular outriggers, precision assembly between the tank and the travel mechanism, etc. as well as professional modular manufacturing lines, robot welding, etc. For more than 20 years, the company is always in the leading position and ranks the first in terms of market share in the domestic market.

Our Workshop

Our Company has employed more than 1,300 people, including approx. 400 R&D professionals, and has workshop area totaling 130,000 m2 .

Main Products

 Semi-trailer

 Bobtail/Rigid Tanker

 ISO Tank /Tank Container

 Spherical Tank

 Horizontal/Mounded/Domestic Storage Tank

LPG Plant/Filling Plant/Autogas Station

LPG/Autogas Filling Skid
